The PTX2000-RV high energy tic tracer is a rugged and reliable non-contact voltage detection instrument ideal for utility, industrial and mine safety applications. The PTX2000-RV warns against dangerous voltages in low and medium voltage applications up to 122 KV without contacting the energized conductor.

PTX2000-RV high energy tic tracers are a utility tool for checking transmission lines, power distribution equipment, down power lines, fuses and load break connectors. PTX2000-RV has a lower voltage setting for checking voltage presence in breaker panels, breakers, power outlets and wiring. The PTX2000-RV has visual and audible voltage indication. The self-test function verifies that the tester works properly.

Features

1、 Non-contact voltage detection:
   30 to 1500 VAC
1500 to 122,000 VAC (w/Hot Stick TIC 410A)

2、Low voltage detection range:
   2.7" at 30 V to 7' 9" at 1500 V

3、 High voltage detection range:
   1' 2" at 1.5 kV to 22' 0" at 122.0 kV
